MRCOOL GeoCool 24K BTU 2 Ton Horizontal Heat Pump GCHPH024TGTANXR

Name: MRCOOL GeoCool 24K BTU 2 Ton Horizontal Heat Pump GCHPH024TGTANXR
Brand: MRCOOL
SKU: GCHPH024TGTANXR
Price: 7619.20 USD
Availability: InStock

MRCOOL | SKU: GCHPH024TGTANXR

$7,619.20 ~~$10,428.68~~

FREE SHIPPING in the Continental US on most orders

NO SALES TAX (Except NV)

Call Us At (800) 407-7770 Or Chat Now To UNLOCK THE BEST PRICE AVAILABLE!

No refunds or returns on any parts order. Parts are sold with NO warranty

In Stock & Ready to Ship

Estimated Delivery in 3-7 business days

MRCOOL GeoCool 24K BTU 2 Ton Horizontal Two-Stage Right Return Geothermal Heat Pump GCHPH024TGTANXR

Why is the MRCOOL GeoCool 24K BTU 2 Ton Horizontal Two-Stage Right Return Geothermal Heat Pump GCHPH024TGTANXR the ideal choice for efficient and versatile home heating and cooling?

The MRCOOL GeoCool 24K BTU 2 Ton Horizontal Two-Stage Right Return Geothermal Heat Pump GCHPH024TGTANXR is the ideal choice for efficient and versatile home heating and cooling. With a 24K BTU capacity and two-stage operation, it provides precise climate control. The horizontal design with a right return facilitates flexible installation in various setups. Utilizing geothermal energy, it reduces utility costs and environmental impact while ensuring reliable comfort year-round.

Features

Qualifies for federal tax credit, and other incentives
Highest energy efficiency in its class
Safety high and low pressure switches
Quiet operation
Full featured sinusoidal eon motor control technology
Insulated sloped stainless steel drain pan
Advanced unit control board with diagnostic LEDs
Double O-ring water connections
Easy service access
Optional domestic water pre-heating
Made in the USA
10 year compressor warranty

Manuals

Manuals:

Specifications

Specifications:

Dimensions	51" D x 23.125" H x 25.75" W
EER	Ground Water (FULL) 27.40 / Ground Loop (FULL) 17.95
EER Part Load	Ground Water (PART) 36.50 / Ground Loop (PART) 25.93
COP 47	Ground Water (FULL) 5.40 / Ground Loop 4.20 (FULL)
COP 47 Part Load	Ground Water (PART) 5.50 / Ground Loop 4.70 (PART)
HSPF	Ground Water Fluid Flow Rate \| COOLING: (PART) 7 - 8 (FULL) / HEATING: (PART) 7 - 8 (FULL)
AFUE	Ground Loop Fluid Flow Rate \| COOLING: (PART) 7 - 8 (FULL) / HEATING: (PART) 7 - 8 (FULL)
CFM	COOLING (PART) 850 - 1000 (FULL) / HEATING (PART) 800 - 950 (FULL)
Tonnage	2
Cooling Capacity	Ground Water (PART) 23000 - 29000 (FULL) / Ground Loop (PART) 21900 - 27000 (FULL)
Heating Capacity	Ground Water (PART) 19000 - 25700 (FULL) / Ground Loop (PART) 16500 - 18500 (FULL)
Voltage	230
Phase	1
Cycle	60
Stage	Two-Stage
Max Fuse Breaker	34.0(W/O Desupe
Min Circuit Ampacity	21.9(
Color	Gray
Color Family	Gray
Max Coverage Area	1000
Refrigerant Type	R-410A
Compressor Motor Type	Scroll
Blower Motor Type	Axial Flux (No Shaft) BLA
Blower Motor HP	3/4
Filter Type	Replaceable
Filter Size	20X37
UL Reconized	No
UL Listed	No
ETL Listed	Yes
ETL Certified	No
LEED Certified	No
ASHRAE Compliant	No
Energy Star Compliant	Yes
Energy Star Certified	Yes
AHRI Certified	Yes
Registered Warranty	10 year registered parts limited warranty & 10 year compressor warranty
Base Warranty	5 year limited parts warranty
Has Batteries	No
Contains Electronics	Yes
Contains Chemicals	Yes
Contains Aerosol	Yes
Contains Compressed Gas	Yes
Proposition 65 Warning	Yes
Restricted States	No
Net Weight	305
Freight Class	85
