Summit 24 inch Built-In Wine Kegerator SBC682PNRWKDTWIN

Enhance your Outdoor Wine Service with the Summit SBC682PNRWKDTWIN Panel Ready Dual Tap Kegerator

Want a commercial-grade dual tap wine kegerator built for custom outdoor or indoor installations?

The Summit SBC682PNRWKDTWIN is a 24-inch wide built-in kegerator designed specifically for wine dispensing. With a panel-ready door and dual tap wine dispensing kit, it's ideal for customized outdoor or indoor bars. The 5.6 cu. ft. interior accommodates a variety of keg sizes, and the unit meets NSF-7 and UL-471 commercial standards. Enjoy quiet operation, digital controls, and a professional wine pour every time.

Note: Panel Not Included

Why Choose Summit?

Summit combines commercial reliability with modern style, offering certified kegerators built for lasting outdoor performance and custom panel integration.

Key Features

• Large Capacity Wine Kegerator: 5.6 cu.ft. interior can accept a full half barrel or quarter keg, or up to three sixth barrels or Cornelius style kegs
• Commercially Approved: ETL-S listed to NSF-7 standards and meets UL-471 for use in commercial settings
• Panel-Ready Door: Extended hinging allows you to install your own panel overlay on the door, creating a custom look to complement or blend into your own cabinetry (panel size: 29 3/4" H x 23 5/16" W at a 3/4" thickness)
• Weatherproof Design: Solid 304 grade stainless steel construction allows placement in the outdoors
• Built-In Capable: Front-breathing design allows fully recessed installation under counters
• Complete Dual Tap Kit: Ships with a complete twin tap wine tap kit that includes a dispenser tower, regulator, and all the connection equipment you need to serve from a 1/6 wine keg or disposable wine keg
• Nitrogen/CO2 Tank Included: Canister is best suited for a 75% nitrogen/25% CO2 mixture
• Dual Tap System: Twin draft tower allows you to serve from two 1/6 (sixtel) sized wine kegs
• Automatic Defrost: Reduced user maintenance with auto defrost operation
• Digital Thermostat: Electronic controls ensure easy temperature management, with an external readout in Celsius or Fahrenheit
• Tap Cool System: Interior tube allows you to extend the cold air flow up into draft tower, ensuring wine freshly tapped stays chilled
• Stainless Steel Floor Cover: Interior includes steel cover to protect the floor when loading kegs
• Top Guard Rail (Ships Unassembled): Attractive chrome guard rail helps to reduce spills and neaten service
• Stainless Steel Drip Tray: Removable two-piece drip tray catches spills to help contain the mess
• Adjustable Shelves: 2 chrome shelves (with six placement options) allow unit to also function as a beverage refrigerator
• Memory IC Function: Recovers the unit's last settings in the case of a power outage or disruption
• Reversible Door: User-reversible door swing for added flexibility
• Casters Included (Ship Unassembled): Four casters (two locking) afford easy portability
• Fully Finished Stainless Steel Cabinet: Allows the dispenser to be used freestanding
• Sealed Back: Space saving design with easier cleanability
• Right Hand Door Swing: Default swing is RHD. For hinges that will allow this door to open from the left, add upgrade "LHDHinge"
• 100% CFC Free: Environmentally friendly design without ozone-damaging chemicals
• CARB Compliant: Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

Manuals for Summit 24-inch Built-In Wine Kegerator

• Product Brochure
• Owner's Manual

Specifications for Summit 24-inch Built-In Wine Kegerator SBC682PNRWKDTWIN

Overview

• Nominal Height: 34.0" (86 cm)
• Height of Cabinet: 33.63" (85 cm)
• Nominal Width: 24.0" (61 cm)
• Width: 23.75" (60 cm)
• Nominal Depth: 25.0" (64 cm)
• Depth: 24.75" (63 cm)
• Depth with Door at 90°: 46.75" (119 cm)
• Capacity: 5.6 cu.ft. (159 L)
• Defrost Type: Automatic
• Door: Panel-Ready
• Cabinet: Stainless Steel
• US Electrical Safety: ETL
• Canadian Electrical Safety: ETL-C
• Sanitation: ETL-S
• Energy Usage/Year: 305.0 kWh/year
• Amps: 1.25
• Voltage/Frequency: 115 V AC/60 Hz
• Weight: 120.0 lbs. (54 kg)

Kegerator

• Door Swing: RHD
• Reversible: Reversible w/ Optional Hinge
• Tap Kit: Yes
• Height with Tap: 51.5" (131 cm)
• Number of Taps: 2
• Adjustable Shelves: Yes
• Shelf Type: Chrome
• Shelf Quantity: 2
• Thermostat Type: Digital
• Fan Type: Interior and Exterior
• Refrigerant: R600a
• Refrigerant Amount: 1.06 oz.
• High Side PSI: 150.0
• Low Side PSI: 50.0
• Interior Height: 26.75" (68 cm)
• Interior Width: 20.0" (51 cm)
• Interior Depth: 19.0" (48 cm)
• Level Legs Quantity: 4
• Wheel Quantity: 4
• Temperature Range: 34°F to 68°F (1°C to 20°C)
• Sound Level: 34.0 dB
