Summit Commercial Back Bar Merchandiser - Stainless Steel Wrapped Cabinet Beverage Fridge SCR700BCSS

Summit Commercial Back Bar Merchandiser - Stainless Steel Wrapped Cabinet Beverage Fridge SCR700BCSS Overview

SUMMIT's SCR700BCSS is a versatile beverage merchandiser designed to maximize impulse sales. This commercially approved refrigerator utilizes automatic defrost for low maintenance use. Two sliding glass doors offer a full view inside the 7.4 cu.ft. hammered aluminum interior, with interior lighting for added product visibility and fan-forced cooling to help improve temperature distribution. Adjustable chrome shelves allow you to rearrange storage to accommodate a variety of sizes. This unit includes a factory installed lock for added security and a digital thermostat for easy temperature management. The SCR700BCSS comes with a stainless steel wrapped cabinet for improved durability and a professional look. This model is ETL-S listed to NSF-7 commercial standards. Set this unit above or below the counter (with proper ventilation) as a self-service refrigerator for impulse buys.

FEATURES

• Back bar design
• Sized at just 20" deep for an easy fit behind the bar
• Commercially approved
• ETL-S Approved to ANSI-NSF Standard 7 for use in commercial establishments
• Automatic defrost
• Reduced maintenance with auto defrost system
• Two sliding glass doors
• Solid glass doors glide open easily while providing a clear view of stored items
• Stainless steel wrapped cabinet
• Durable construction with a professional look
• Digital thermostat
• Electronic controls located in the front kickplate for easy temperature management
• Factory installed lock
• Single keyed lock for sliding doors, with two keys included
• Adjustable shelves
• Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up
• Internal fan
• Fan-forced cooling ensures the unit is evenly cooled from top to bottom
• Interior light
• Illuminates the interior for a an attractive view of stored contents
• 100% CFC free
• Environmentally friendly design without ozone-damaging chemicals

SPECIFICATIONS

Overview
Height of Cabinet	34.13" (87 cm)
Width	35.5" (90 cm)
Depth	20.25" (51 cm)
Capacity	7.4 cu.ft. (210 L)
Defrost Type	Automatic
Door	Glass
Cabinet	Stainless Steel
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Sanitation	ETL-S
Amps	1.2
Voltage/Frequency	115 V AC/60 Hz
Weight	135.0 lbs. (61 kg)
Shipping Weight	140.0 lbs. (64 kg)
Estimated Time to Ship	2 to 4 days
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
Refrigerator Features
Door Swing	Sliding
Shelf Type	Chrome
Shelf Qty	4
Adjustable Shelves	Yes
Thermostat Type	Digital
Fan Type	Interior
Refrigerant Type	R600a
Refrigerant Amount	1.92oz.
High Side PSI	215.0
Low Side PSI	60.0
Interior Light	Yes
Dimensions
Interior Height	28.25" (72 cm)
Interior Width	32.25" (82 cm)
Interior Depth	15.0" (38 cm)
Compressor Step Height	7.25" (18 cm)
Compressor Step Width	32.25" (82 cm)
Compressor Step Depth	7.25" (18 cm)



MANUALS



BROCHURE w/ DRAWINGS
SCR700BCSS.pdf





TECHNICAL DRAWING (.dwg)
SCR700BEVERAGECENTERA-C2000.dwg





TROUBLESHOOTING
How_to_disable_the_digital_thermostat_evaporator_sensor.pdf





USE & CARE
SCR700B_SCR7012DB_Manual_3-29-2019.pdf
