Summit Single Tap Wine Kegerator SBC635MWKD

• Large interior
• 5.6 cu.ft. interior allows you to store an extra 1/6 size wine keg inside
• Tap Kit
• Ships with a complete wine tap kit that includes a dispenser tower, regulator, and all the connection equipment you need to serve from a 1/6 wine keg or disposable wine keg
• Automatic defrost
• Reduced user maintenance with auto defrost operation
• Digital thermostat
• Electronic controls ensure easy temperature management, with an external readout in Celsius or Fahrenheit
• White wine/rosé temperature
• Operates between 33º and 50ºF to keep a variety of white and blush wine chilled
• Nitrogen/CO2 tank included
• Canister is best suited for a 75% nitrogen/25% CO2 mixture
• Reversible door
• User-reversible door swing for added flexibility
• Casters included (ships unassembled)
• To make the dispenser portable, install this set of 2 1/2" high locking casters
• Top guard rail (ships unassembled)
• Attractive chrome guard rail helps to reduce spills and neaten service
• Stainless steel floor cover
• Interior includes steel cover to protect the floor when loading kegs
• Cleaning kit included
• Kit includes everything you need to keep your wine kegerator clean
• Drip tray
• Removable drip tray catches spills to help contain the mess
• Fully finished black cabinet
• Allows the unit to be used freestanding
• 100% CFC free
• Environmentally friendly design without ozone-damaging chemicals

SPECIFICATIONS

Overview
Height of Cabinet	33.5" (85 cm)
Width	23.63" (60 cm)
Width with Door Open	25.0" (64 cm)
Depth	25.0" (64 cm)
Depth with door at 90°	47.0" (119 cm)
Capacity	5.6 cu.ft. (159 L)
Defrost Type	Automatic
Door	Black
Cabinet	Black
US Electrical Safety	UL
Canadian Electrical Safety	ULC
Amps	0.86
Voltage/Frequency	115 V AC/60 Hz
Weight	80.0 lbs. (36 kg)
Shipping Weight	83.0 lbs. (38 kg)
Estimated Time to Ship	3 to 5 days
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
Kegerator
Door Swing	RHD
Reversible	Yes
Tap Kit	Yes
Height with Tap	49.0" (124 cm)
Number of Taps	1
Thermostat Type	Digital
Refrigerant	R600a
Refrigerant Amount	1.13 oz.
High Side PSI	250.0
Low Side PSI	110.0
Inter Height	28.0" (71 cm)
Interior Width	20.5" (52 cm)
Interior Depth	19.0" (48 cm)
Compressor Step Height	8.25" (21 cm)
Wheel Qty	4
Temperature Range	33º to 50º F
