MRCOOL Universal 24K- 36K BTU Heat Pump Condenser MDUO18024036

Name: MRCOOL Universal 24K- 36K BTU Heat Pump Condenser MDUO18024036
Brand: MRCOOL
SKU: MDUO18024036
Price: 2806.00 USD
Availability: OutOfStock

MRCOOL | SKU: MDUO18024036

MRCOOL Authorized Dealer badge – trusted retailer for MRCOOL mini split systems, HVAC units, and home comfort solutions.

Sold out

26% off

$2,806.00 $3,788.10

FREE SHIPPING in the Continental US on most orders

NO SALES TAX (Except NV)

Call Us At (800) 407-7770 Or Chat Now To UNLOCK THE BEST PRICE AVAILABLE!

No refunds or returns on any parts order. Parts are sold with NO warranty

In Stock & Ready to Ship

Estimated Delivery in 3-7 business days

MRCOOL Universal Series DC Inverter24K- 36K BTU 2-3 Ton, Heat Pump Condenser MDUO18024036

This product is no longer available, Our sales professionals can help you in finding something similar that matches your style, space, and budget. Feel free to contact us today at +1-888-407-7770 or email us at support@winecoolersempire.com.

The MRCOOL Universal Series DC Inverter 24K-36K BTU 2-3 Ton Heat Pump Condenser MDUO18024036 is an excellent choice due to its high efficiency, offering up to 20 SEER with R410A refrigerant. Operating on 208-230V/1Ph/60Hz, it supports a broad BTU range, making it versatile for different space sizes. The DC Inverter technology ensures enhanced energy savings and precise temperature control, providing reliable heating and cooling performance while minimizing energy costs.

Features:

Up to 20 SEER
Ultra Wide Operating Temperature Range
Gas Furnace Not Required
Slim design allows more storage for warehouse inventory
Compatible with any third party air handler and thermostat including WiFi/Nest
Ideal for zero lot line homes, strict sound restriction, conventional installations, and unit replacements
Rapid cooling and heating
Internal Fan Blade Creates Low Noise
Maximum savings while running
Factory Charged
ETL and AHRI certified

Manuals

Manuals:

Specifications

Specifications:

Product Dimensions	37"W x 18-1/8"D x 32-1/4"H
Product Weight	217.2 lbs
SEER	up to 20
Max SEER	20
EER	11
HSPF	10
CFM	3470
Tonnage	2-3 Ton
Cooling Capacity	36,000 BTU
Heating Capacity	36,000 BTU
Electrical Requirements	Requires a minimum of 208V-230V/60HZ/24A-35A (please check your home meets this electrical requirement prior to purchase)
Phase	1
Cycle	60 Hz
Max Fuse Breaker	35 A
Min Circuit Ampacity	24 A
Color	Gray
Refrigerant Type	R-410A
Refrigerant Volume	148.8 oz
Decibel Rating	57 dBA
Inverter	DC
Min Ambient Cool	5F - 129.2F
Min Ambient Heat	-22F - 75.2F
Lineset Included	No
Line Set Length	15ft, 25ft, 35ft, 50ft
Max Lineset Length	164 FT / 5
Lineset Fitting Type	Pre-Flared/Sweat & Quick Connect
Liquid Line Size	3/8 in
Suction Line Size	3/4
Compressor Motor Type	Inverter Rotary
Condenser Fan Motor Type	Direct Drive
Condenser Fan Motor RPM	820
Metering Device	EEV
Auxiliary Heater Available	Yes
Certifications	ETL Energy Star AHRI
Warranty	10 Year Registered Limited Warranty 5 Years Parts
Restricted States	No
